Laser Scribing Machine
| Parameter | YMS-50D | YMS-20F |
|---|---|---|
| Laser material | YV04 | Fiber |
| Laser wavelength | 1064mm | 1064mm |
| Pump source | Side-end pump | Fiber |
| Beam power | 50W | 20W |
| Cutting speed | 120mm/s | 250mm/s |
| Cutting depth | Max 1.2mm | |
| Min line width | 0.03mm | 0.02mm |
| Frequency | 0.5-50nKHz | 20-250nKHz |
| Power supply | 220V AC. ±10%, 50-60Hz, <1.5KW | 220V AC. ±10%, 50-60Hz, <1KW |
| Cutting area | 300x300mm | 300x300mm |
| Input power | 1.5KW | 1.0KW |
