Laser Technology Machine
| Model | KBF-FB20JK1 |
| Laser source | JPT |
| Power | 20W |
| Repeat freq. range | 1-80KHz |
| Cooling system | Air cooling |
| Net weight | 30KG |
| Software | >Ezcard 2.99 |
| Laser type | Fiber laser |
| Wavelength | 1064mm |
| Laser software | >Ezcard or equivalent |
| Scanner | Zino/CT or equivalent |
| Min. line width | 0.01mm |
| Laser safety level | High level |
| Rotary attachment | Min. 60mm dia |
| Cooling method | Built in wind cooling |
| Work table size | Min 180*180mm |
| Electrical Power requirement | AC 220V ± 10%, 1Ph, 50/60Hz |
| Machine model | SKBF-FB20JK1 |
| Machine type | Fully enclosed |
| Laser source life | 80,000hours |
| Marking and engraving area | 2.0x5.0 to 180.0x180.0mm |
| Line width of engraving | 0.05mm |
| Material | Metal, plastic & ceramic, Stainless steel, Carbon steel, aluminum- fold or electro less plated, Brass, Copper, Alumina subtract |
| Laser wavelength | >1064mm |
| Scanner | Sino/Ouya |
| Control card | JCZ |
| Marking area | >180*180mm |
| Size | 440*440*630mm |
| Power input | 220V, 50Hz |
| Mirror/focal lenses | Wavelength |
| Laser technology | Specify to match below materials |
| Pulse repetition frequency | Adjustable |
| Beam quality | 1.3 to 1.6 |
| Marking speed | 7000 mm/sec |
| Engraving depth | ≥0.2mm |
| XY table | Manual |
| Laser safety window | Enclosure considered |
| Power | 20W |
| Power consumption n | Approx. 1KW |
| Software | PC/Laptop with original licensed window software |
| Laser source | JPT |
| Warranty | 2 years |
| Marking type | Cylindrical and flat |
| Rotary attachment | Up to 60mm dia |
| Minimum job height | 140mm |
